Stainless Steel Fittings
Basic Introduction
Duplex & super duplex fittings are most selling fittings in world & now we are also producing forged as per client’s drawing. Duplex stainless steels pipe fittings have higher strength and exhibit higher corrosion resistance as compared to SS 304 fittings and SS 316 pipe fittings.
We are manufacturing stainless steel flange including threaded flange, blind flange, lap joint flange, weld neck flange, slip on flange, socket weld flange, and plate flange. We can manufacture these stainless steel flange in custom shape flanges or as per client’s drawing.
Bestar Steel engaged in manufacturing high quality stainless steel pipe bends with bending radius ranging from R=3D-10D and bending angle of 10 degree to 180 degree. In addition, we can also manufacture stainless steel bends as per custom requirements of our esteemed clients. All our stainless steel fitting and flange are produced & supplied with relevant test certificates of raw materials.
These industrial stainless steel pipe fittings and stainless steel flanges are used in precious industries like petroleum, chemical industry, pharmaceuticals, nuclear power, power generation, aerospace, shipbuilding, water supply.
Stainless Steel Pipe Fittings Range & Specification
| Specification | ASTM A182 / A403 & ASME SA182 / SA403 |
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Stainless Steel Pipe Fittings Type | Seamless / Welded / Fabricated
|
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Range | ½" NB to 48" NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
High Pressure Forged Stainless Steel Pipe Fittings
Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Stainless Steel Flanges Range & Specification
| Specification | ASTM A182 / A240 & ASME SA182 / SA240 |
| Grade | 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Size | 1/8″ to 36″/ |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
